Cut-to-Length (CTL)
Cut-to-Length (CTL)
Discover precision redefined with our exclusive Cut-to-Length (CTL) services at SMPC Industries. Tailored to meet the diverse needs of your industry, our CTL services combine state-of-the-art technology with expertise to deliver custom-cut sheet metal with unmatched accuracy.
Tailored Lengths for Every Application
With our advanced CTL services, we offer custom-cut sheet metal to your exact specifications. Whether you require specific lengths for manufacturing or construction, our expertise ensures precision in every cut.
Material Flexibility
Our CTL services cater to a variety of materials, from CR, HR, HRPO, stainless steel to aluminium and more. This flexibility, paired with our skilled team, allows us to handle diverse materials with ease and accuracy.
Dimensional Consistency
Precision is the hallmark of our CTL services. We guarantee dimensional consistency across all cut pieces, meeting the highest industry standards for quality and accuracy.
Our CTL Machinery
Our advanced precision shears are equipped to handle a variety of materials, providing clean and accurate cuts for every piece. The state-of-the-art cut-to-length lines are designed for efficiency, ensuring precise and consistent cuts across the entire length of the material.
| Machine Line | CTL Line 1 | CTL Line 2 | CTL Line 3 | CTL Line 4 |
| Manufacturer | IOWA | SONADA | Blue Sky | KOWA KOKEN |
| Origin | USA | JAPAN | CHINA | JAPAN |
| Feed coil max. Wt. | 25 MT | 15 MT | 30 MT | 5 MT |
| Feed coil max. OD | 1625 mm | 1800 mm | 2000 mm | 1500 mm |
| Feeding coil ID (mm) | 508 to 610 | 508 to 610 | 508 to 760 | 508 to 610 |
| Thickness (mm) | 0.30 to 3.10 | 0.30 to 1.60 | 3.0 to 12.00 | 0.30 to 2.00 |
| Width (mm) | 300 to 1500 | 200 to 1300 | 800 to 2000 | 100 to 650 |
| Capacity (MT/month) | 2000 | 2500 | 3000 | 1200 |
| Output Length (mm) | 600 to 4000 | 300 to 3200 | Up to 9000 | 300 to 2000 |
| Speed (m/min) | 30 | 80 | 30 | 50 |
| Output Coil / Bundle wt. | Up to 5 MT | Up to 5 MT | Up to 8 MT | Up to 2 MT |
| Tolerance | Length: +/- 2 mm Diagonal: -2 / 2500 mm | Length: +/- 1 mm Diagonal: -1 / 2500 mm | Length: +/- 1 mm Diagonal: -1 / 2000 mm | Length: +/- 1 mm Diagonal: -1 / 2000 mm |
| Burr level | < 50 microns | < 50 microns | < 50 microns | < 50 microns |
| Camber | -- | -- | -- | -- |
| Advantage | * Rough leveler (Ø 130 X 07 rolls) * Fine Leveler (Ø50 X 17 rolls) * 6 Roll High Leveler | * Rough leveler (Ø90 X 11 rolls) * Fine Leveler (Ø50 X 21 rolls) * 4 Roll High Leveler | * Rough leveler (Ø130 X 7 rolls) * Fine Leveler (Ø50 X 17 rolls) * 6 Roll High Leveler | * Loop Mode at Pre- Shearing * Fine Leveler (Ø40 X 15 rolls) * 4 Roll High Leveler |
| UTS (MPA) | 480 | 550 | 500 | 600 |
| YS (MPA) | 340 | 380 | 400 | 450 |
Contact us today to discuss your CTL requirements and witness how SMPC Industries can be your trusted partner in precision sheet metal processing.
